Hinges and Plates

HINGE PLATE

PART NUMBER

HINGE W / GROMMET

PART NUMBER

Soft Close Hinge

HNG, 35MM, SFT CLS, CLIP

R20400

HINGE PLATE, SOFT CLOSECLIP ON

R20401

Frame Hinge

HINGE / PLATE, 35MM, 1 / 2 " OVRLAY

R20090A

N / A

N / A

Diagonal Corner Hinge

HINGE, 35MM, DIAGONAL 45

R20404

MOUNTING PLATE W / EURO SCREWS

R20403

EZ / LS Cabinet Hinge

HINGE, 35MMX165 DEGREE

R20583L

MOUNTING PLATE W / EURO SCREWS

R20582L

EZ / LS Knuckle Hinge

HINGE, CRNR KNUCKLE, BLS36 LCC

R20584L

MOUNTING PLATE W / EURO SCREWS

R20582L

SPECIALTY PARTS & ACCESSORIES

Premium Drawer Parts & Hardware

• Drawer Hardware

• R20459

• R20440

DESCRIPTION Ball Bearing Glide, 150 lb, File & Pots / Pans Ball Bearing Glide, 18” Low Profile, Knee Drawer Wood Soft Closing Glide Set, Kitchen Wood Soft Closing Glide Set, Vanity Set, Metal Drawer Upper Kit Depth Set, Metal Drawer Lower Kit Depth

PART NUMBER R20459 R20460 R20440 R20441 PDSU24 PDSL24

Set, Metal Drawer Upper Van Depth

PDSU21

Set, Metal Drawer Lower Van Depth

PDSL21

Bracket Pair, Metal Drawer, Left & Right

PDBRKT

Cab Glide Pair, Standard, Kitchen Depth

PDG24

Cab Glide Pair, Standard, Vanity Depth

PDG21

Vertical Lift-Up Door Systems

DESCRIPTION

PART NUMBER

Lift-up Hardware Kit for Wall Lift Up Cabinets( WLU)

R20490

Lid Stay Gas Cylinder for Flip Up Doors( WFL)

R20453GS

Knob Screws( AHS)

DESCRIPTION

PART NUMBER

Truss Head, 8 / 32” x 1 / 2”

AHS12

Truss Head, 8 / 32” x 5 / 8”

AHS58

Truss Head, 8 / 32” x 1-1 / 8”

AHS118

NOTE: Quantity of 1 = Pack of 100 Screws

Truss Head, 8 / 32” x 1-5 / 8”

AHS158

Production Screws( R14400)

DESCRIPTION

PART NUMBER

NOTE: Quantity of 1 = Pack of 100 Screws

Screw, Euro-Type 6mm x 11mm PC

R14400-Q100
