Decorative End Panels for Tall Cabinets
• Must be field installed.
• All Tall cabinets require two separate door orders.
• Decorative End Panels ordered and packaged separately.
• Can be fastened to the side of any standard size cabinet.
• Actual size of end panels 1 / 8” smaller in both width and height than the dimension code.
•( Example: D2430 actual size is 23 7 / 8” x 29 7 / 8”)
• Finished ends should also be ordered to cover exposed areas.
|
DEPTH 12 INCHES
Order both doors to fit 84” overall height Order both doors to fit 87” overall height Order both doors to fit 90” overall height Order both doors to fit 93” overall height Order both doors to fit 96” overall height
DEPTH 18 INCHES
Order both doors to fit 84” overall height Order both doors to fit 87” overall height Order both doors to fit 90” overall height Order both doors to fit 93” overall height Order both doors to fit 96” overall height
|
TOP DOOR
D1230 D1233 D1236 D1239 D1242
TOP DOOR
D1830 D1833 D1836 D1839 D1842
|
BOTTOM DOOR
D1249 D1249 D1249 D1249 D1249
BOTTOM DOOR
D1849 D1849 D1849 D1849 D1849
|
|
DEPTH 21 INCHES
Order both doors to fit 84” overall height
|
TOP DOOR
D2130
|
BOTTOM DOOR
D2149
|
|
Order both doors to fit 87” overall height |
D2133 |
D2149 |
|
Order both doors to fit 90” overall height |
D2136 |
D2149 |
|
Order both doors to fit 93” overall height Order both doors to fit 96” overall height |
D2139 D2142 |
D2149 D2149 |
|
|
DEPTH 24 INCHES
Order both doors to fit 84” overall height
|
TOP DOOR
D2430
|
BOTTOM DOOR
D2449
|
|
Order both doors to fit 87” overall height |
D2433 |
D2449 |
|
Order both doors to fit 90” overall height |
D2436 |
D2449 |
|
Order both doors to fit 93” overall height Order both doors to fit 96” overall height |
D2439 D2442 |
D2449 D2449 |
