32
SPECIALTY BASE CABINETS
|
Dishwasher Return( BDE / BDEC)
BDE3
Finished Side
|
|
|
|
WIDTH INCHES
3
MODEL NUMBER
BDE3
|
• Side panel is same depth as standard cabinet, fascia flush with doors
• Finished on 1 side only
• Use 3” if end requires electrical outlet
|
34 1 / 2” |
BDEC1
Finished Side
WIDTH INCHES
1 1 / 4
|
MODEL NUMBER
BDEC1
|
24 1 / 2” |
|
24 1 / 2” |
|
|
4” 3” 4” 1 1 / 4”
Base Column & Fluted Column Box( BCB / BCBF) Base Column
WIDTH INCHES
3
MODEL NUMBER
BCB3
• Side panels are same depth as standard cabinet, fascia flush with doors
• Finished ends standard
Base Fluted Column
WIDTH INCHES
3
MODEL NUMBER
BCBF3
Roll-Outs Standard Kit( AROSTD)
BASE CABINETS
• Comes in a kit of 2
• For Tall Cabinets, 2 kits are required
• Holes are pre-drilled for easy roll-out installation
MODEL NUMBER AROSTD
Roll-Outs( Loose) for Cabinets( ARO)
• Must be Field Installed
• Must order AROSTD( above) for installation
• Upgrade drawer available, must specify Dovetail( DT)
SINGLE DOOR
WIDTH INCHES
12 15 18 21 24
MODEL NUMBER
ARO12 ARO15 ARO18 ARO21 ARO24S
DOUBLE DOOR
WIDTH INCHES
24 27 30 33 36 39 42
MODEL NUMBER
ARO24 ARO27 ARO30 ARO33 ARO36 ARO39 ARO42
Decorative End Panels for Base Cabinets
• Must be field installed.
• Decorative End Panels ordered and packaged separately.
• Can be fastened to the side of any standard size cabinet.
• Actual size of end panels 1 / 8” smaller in both width and height than the dimension code( Example: D2430 actual size is 23 7 / 8” x 29 7 / 8”).
• Finished ends should also be ordered to cover exposed areas.
WIDTH INCHES
24
MODEL NUMBER
D2430
