2017 RSI PCS Product Specification Guide Volume 1 | Page 21

SPECIALITY WALL CABINETS 21

Framed Open Wall Cabinet 12” Deep( WOS)
12”
• Wood frames are 1 1 / 2” wide
• Thermofoil frames are 2” wide
• Interiors will match exterior finished ends in either laminate or real wood veneer. Oak is not available in real wood veneer.
• All components tops, bottoms, backs and shelves are made with 5 / 8” laminate furniture board.
WIDTH INCHES
15 18 21 30 36
30” HEIGHT
WOS1530 WOS1830 WOS2130 WOS3030 WOS3630
36” HEIGHT
WOS1536 WOS1836 WOS2136 WOS3036 WOS3636
42” HEIGHT
WOS1542 WOS1842 WOS2142 WOS3042 WOS3642
Framed Open Wall Cabinet 15” Deep( WOS)
15”
• Wood frames are 1 1 / 2” wide
• Thermofoil frames are 2” wide
• Interiors will match exterior finished ends in either laminate or real wood veneer. Oak is not available in real wood veneer.
• All components tops, bottoms, backs and shelves are made with 5 / 8” laminate furniture board.
WIDTH INCHES
15 18 30 36
30” HEIGHT
WOS153015 WOS183015 WOS303015 WOS363015
36” HEIGHT
WOS153615 WOS183615 WOS303615 WOS363615
42” HEIGHT
WOS154215 WOS184215 WOS304215 WOS364215
WALL CABINETS
Decorative End Panels for Wall Cabinets
DEPTH INCHES
12 15
12” HEIGHT
D1212
D1512
15” HEIGHT
D1215 D1515
18” HEIGHT
D1218 D1518
21” HEIGHT
D1221 D1521
24” HEIGHT
D1224 D1524
30” HEIGHT
D1230 D1530
36” HEIGHT
D1236 D1536
42” HEIGHT
D1242 D1542
• Must be field installed.
• Decorative End Panels ordered and packaged separately.
• Can be fastened to the side of any standard size cabinet.
• Actual size of end panels 1 / 8” smaller in both width and height than the dimension code.
• Finished ends should also be ordered to cover exposed areas.
