Wall Easy Reach Corner Cabinet( WEZ)
• Not available with soft close hinge
• Must specify Left or Right( L / R)
• Not Available in Tripoli Door
|
WIDTH INCHES
21 24
|
30” HEIGHT
WEZ2130L / R WEZ2430L / R
|
36” HEIGHT
WEZ2136L / R WEZ2436L / R
|
42” HEIGHT
WEZ2142L / R WEZ2442L / R
|
12” |
WALL CABINETS |
12” x 24” 15” x 27”
Wall Diagonal Corner Glass Door Cabinet( WCGD)
|
• Not available with soft close hinge
• Must specify Left or Right( L / R)
• WC Available in Tripoli Door
WCGD models:
• Optional glass styles are available-page 17
• Interiors will match exterior finished ends in either laminate or real wood veneer. Oak is not available in real wood veneer.
• All components tops, bottoms, backs and shelves are made with 5 / 8” laminate furniture board.
|
WIDTH INCHES
24 27
Glass Door
WIDTH INCHES
24 27
30” HEIGHT
WC2430L / R WC273015L / R
30” HEIGHT
WCGD2430L / R WCGD273015L / R
36” HEIGHT
WC2436L / R WC273615L / R
36” HEIGHT
WCG2436L / R WCG273615L / R
12 1 / 4” 15 1 / 4”
42” HEIGHT
WC2442L / R WC274215L / R
42” HEIGHT
WCGD2442L / R WCGD274215L / R
|
Wall Blind Corner Cabinet w / 1 Door( WB) |
• Hinging specifications indicate the position of the blind side( i. e., left hinge means blind is on the left)
• Not available with soft close hinge
• Must specify Left or Right( L / R)
• 24” Not available in Tripoli Door
• 27” – 36” Available in Tripoli Door
|
WIDTH INCHES
24 27 30 33 36
|
30” HEIGHT
WB2430L / R WB2730L / R WB3030L / R WB3330L / R WB3630L / R
|
36” HEIGHT
WB2436L / R WB2736L / R WB3036L / R WB3336L / R WB3636L / R
|
42” HEIGHT
WB2442L / R WB2742L / R WB3042L / R WB3342L / R WB3642L / R
|
|||
12” |
||||||||
|
Wall Blind Corner Cabinet w / 2 Doors( WB)
• Hinging specifications indicate the position of the blind side( i. e., left hinge means blind is on the left)
• Not available with soft close hinge
• Available in Tripoli Door
|
WIDTH INCHES
39 42 45
|
30” HEIGHT
WB3930 WB4230 WB4530
|
36” HEIGHT
WB3936 WB4236 WB4536
|
42” HEIGHT
WB3942 WB4242 WB4542
|
12” |
C
A
D
Shown as left
B
Blind Wall Cabinets can be set to the code’ s width. Example a WB3630 can be set at 36 " which leaves a 3” space.
A Min. of 1 " filler must be used to clear adjacent cabinet.
|
CABINET
WB24xx WB27xx WB30xx WB33xx WB36xx WB39xx WB42xx WB45xx
|
A
BOX WIDTH INCHES
21 24 27 30 33 36 39 42
|
B
DOOR WIDTH INCHES
9 12 15 18 21 2 x 12 2 x 13 2 x 15
|
C
MIN PULL INCHES
22 25 28 31 34 37 40 43
|
D
MAX PULL INCHES
26 29 32 35 38 41 44 47
|
