Phoenix™ USA, Inc. Phone 931.526.6128 • Fax 931.526.1795
Heavy Duty
Mesh Bottom Basket
New strengthened configuration
with solid sides and mesh bottom
only. Powder coated, solid metal
construction.
Part Number Description
Outside Dimensions
Weight
SUBMB36
36” bottom mesh basket
36L x 18D x 18H
48 lbs.
SUBMB48
48” bottom mesh basket
48L x 18D x 18H
58 lbs.
SUBMB60
60” bottom mesh basket
60L x 18D x 18H
90 lbs.
Dress Plate for Bottom Mesh Basket
Part Number
Description
SUBMB36DP 36” bottom mesh basket dress plate
SUBMB48DP 48” bottom mesh basket dress plate
SUBMB60DP 60” bottom mesh basket dress plate
Underbody Mesh Drawer
Part Number Description
SSUD30
Underbody mesh Drawer
Outside Dimensions
Weight
30L x 28.5D x 18.5H
105 lbs.
Underbody mesh basket with stainless steel pull-out drawer.
Shipping Dimensions: 28”L x 30.5”D x 18”H
Inner Drawer Dimensions: 27” x 25.5”
Buckets and straps
not included.
- 34 -
• Powder coated, solid metal construction.
• Auto-close latch
• Polished stainless fascia door
• Pull-out mesh basket
• Multiple hook locations for secure load
transport
• Working load limit of 500 lbs.
• Stainless rollers
• Holes on all sides of basket for easy
strapping
