Sensaphone WSG30 Wireless Sensors
The Sensaphone WSG30 also offers monitoring critical conditions at
remote locations without running wires. Based on proven Sensaphone
remote monitoring methods, the WSG30 has the ability to read sensor
status from wireless sensors. And not just simple on/off status or open/
closed conditions. The wireless technology includes full analog capability
so real world values can be monitored, like actual temperatures, real tank
levels, and flow rates.
The Sensaphone WSG30 can accept up to thirty wireless sensors. A
variety of wireless sensor types are available to choose from in addition
to two wireless interface modules. The interface modules allow you to
WSG
Wireless
Temperature Sensor
connect to existing equipment and transmit their status back to
the WSG30.
The WSG30 Wireless Sensors all include a built in radio transmitter and
run on AA batteries which will power the sensors for up to two years. An
optional plug-in power supply is also available if one isn’t supplied with
the sensor. The batteries become a backup if main AC power fails. The
wireless sensors can be placed up to 300’ | 91m away from the WSG30
or much farther with a line of sight. The sensors also can create a mesh
network that would expand the wireless sensor range.
WSG
Wireless
Includes a temperature element for monitoring
temperatures wherever the device is installed. This sensor
will monitor temperatures from 32° to 115°F | 0° to 46°C.
Power Failure Sensor
Includes a wall plug in power supply that will detect the loss
of power at the outlet where the power supply is attached.
Two AA batteries will power the sensor and allow it to
transmit alarms in the event of a power outage.
WSG Wireless Temperature Sensor . . . . . FGD-WSG30-TMP
WSG Wireless Power Failure Sensor . . . . FGD-WSG30-PWR
Temperature Sensor w/ Probe
WSG
Wireless
Includes a temperature probe for monitoring in a harsh
environment such as a refrigerator or freezer. The sensor
will monitor temperature from -109° to 115°F | -85° to 46°C.
In temperatures below -20°F use part number FGD-WSG30-TEX85.
WSG Wireless Temperature Sensor w/
External Probe . . . . . . . . . . . . . . . . . . . FGD-WSG30-TEX
WSG Wireless Ultra Low Temperature
Sensor w/External Probe . . . . . . . . . . .FGD-WSG30-TEX85
WSG
Wireless
WSG Wireless Dry Contact Bridge . . . . . . FGD-WSG30-DRY
WSG
Wireless
Includes a 4-20mA input and 24V loop power supply. The
sensor can be used to monitor the output of any 4-20mA
transducer. Comes with plug in power supply.
WSG Wireless 4-20mA Bridge . . . . . . . . . FGD-WSG30-4-20
WSG
Wireless
Humidity Sensor
Includes a humidity sensor element for monitoring humidity
from 0 to 95% wherever the device is installed.
Spot Water Detection Sensor
Includes water sensing probes for monitoring the presence
of water at a particular location.
Dry Contact Bridge
Includes input terminals for connecting to any
normally-open or normally-closed output. Use of this device
with solid state outputs is not recommended.
4-20mA Bridge
WSG Wireless Spot Water
Detection Sensor . . . . . . . . . . . . . . . . FGD-WSG30-SPOT
WSG
Wireless
Zone Water Detection Sensor
Includes 10’ of water sensing cable for monitoring for the
presence of water in a particular area. Additional lengths
can be added to increase the monitored area.
WSG Wireless Zone Water
Detection Sensor . . . . . . . . . . . . . . . . FGD-WSG30-ZONE
WSG Wireless Humidity SensorFGD-WSG30-HUM
