Sensaphone SCADA 3000 Accessories
SCADA
3000
SCADA 3000 Universal Input Expansion Module
The SCADA 3000 Universal Input Module is an optional component for use with the SCADA
3000 system. The input channels are identical to those included on the SCADA 3000 main unit.
The Universal Input Module features eight channels that can be configured to interface with
several different types of sensors and transducers, including: Normally Open/Normally Closed dry
contacts, digital logic, run time accumulation, 0–5V analog, 4–20mA analog and 10K thermistor
(ºC & ºF).
Part Name
Part Number
SCADA 3000 Universal Input Expansion Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FGD-3010
SCADA
3000
SCADA 3000 Pulse Count Module
The SCADA 3000 Pulse Count Module features four totalizing pulse count channels and four virtual
channels that can be programmed to calculate various rates or to display count overflow. The four
pulse count channels are capable of counting pulses at a rate of up to 10,000 pulses per second
(10KHz). Each channel will totalize pulses up to one million and then reset to zero. The four virtual
channels can be programmed to calculate the pulse as either pulses per second, pulses per minute,
or pulses per hour.
SCADA
3000
SCADA 3000 Relay Output Module
The SCADA 3000 Relay Output Module is an optional component for use with the SCADA 3000
system. The output channels are identical to those included on the SCADA 3000 main unit. The
Relay Output Module features eight latching relay outputs that can be used to switch equipment
on and off. The relays are rated at 2 Amps at 125VAC and have integral contact protection. They
may be controlled manually or automatically via a ladder program or C-program. In addition, a
microprocessor watchdog circuit is integrated to maintain system reliability. LED indicators are
provided to show system power and module operation via a blinking pulse LED.
Part Name
Part Number
SCADA 3000 Relay Output Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FGD-3040
SCADA
3000
SCADA 3000 Analog Output Module
The SCADA 3000 Analog Output Module features four analog output signals that can be configured
as 4–20mA, 0–20mA, or 0–10V. The outputs can be used to control equipment, drive digital
displays, or provide information to other computer devices. The individual outputs are capable of
driving up to 1000 Ohms. They may be controlled automatically via a ladder program or C-program.
The module also features a microprocessor watchdog circuit to maintain system reliability. LED
indicators are provided to show system power and module operation via a blinking pulse LED.
Part Name
Part Number
SCADA 3000 Analog Output Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FGD-3050
www.sensaphone.com
49
Accessories & Sensors
Part Name
Part Number
SCADA 3000 Pulse Count Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FGD-3020
