CLOTH HEATING JACKETS
How to Order:
CLOTH HEATING JACKETS
Cloth Jacket Design Options
Your Heating Specialist since 1949
CLOTH HEATERS AND INSULATORS
What are the Different Parts of a Cloth Jacket?
Liner and Facing Material( Inside and Outside cloth material):
• PTFE- Standard facing material. Up to Class 10 environments. Exposure temperature up to 500˚F( 260˚C).
• BriskClean Cloth- For cleanroom Class 10 environments. Exposure temperatures up to 600˚F( 315˚C).
• Silicone Cloth- Adds moisture and chemical resistance. Exposure temperatures up to 500˚F( 260˚C).
• Samox ®- Highest temperature material. Up to Class 100 environments. Exposure temperatures up to 1100˚F( 593˚C)
• Aluminum- Facing material option. Exposure temperature up to 450˚F( 232˚C).
• Fiberglass Cloth- Liner material option. Exposure temperature up to 900˚F( 482˚C). Up to Class 100 environments.
Closure Options:
• Hook and Loop Fastener
• Hook and Lace
• Grommets
Voltage Options:
• 120-600 VAC
• Single Phase
• 3 Phase( Wye)
• 3 Phase( Delta)
• 60 Hz.
• 50 Hz.
• DC
Built-in Controlling / High Limit Thermostat Options:
• 180 ° F( 82 ° C)
• 347 ° F( 175 ° C)
• 248 ° F( 120 ° C) • 392 ° F( 200 ° C)
• 302 ° F( 150 ° C) • 500 ° F( 260 ° C) Other Temperatures Available
Built-In Low-Limit Alarm Thermostat Options:
• 180 ° F( 82 ° C) with 30 ° F( 17 ° C) differential
• 248 ° F( 120 ° C) with 50 ° F( 28 ° C) differential Other Temperatures Available
Insulation( placed in between liner and facing): Fits your application based upon process temperatures. BriskHeat’ s industry leading engineers will design your system with the correct amount of insulation. Insulation will make your system energy efficient and touch-safe.
Power Plug / Connector Options:
• Mate-N-Lock
• Bare Wire
• Twist Lock
• Other Electrical
• CPC Connector Connections Available
Temperature Sensor Options:
• Platinum RTD PT100
• Type J Thermocouple
• Type K Thermocouple
• Thermistor
PTFE
BriskClean
Silicone Samox ®
Aluminum
Fiberglass
• Other Temperature Sensors Available
Insulated for Superior Thermal Efficiency and Cool-to-the-Touch Safety
Durable and Flexible Mutli-stranded Resistance Wire
Patented Grounded Heating Element for Your Safety
How to Order:
Resistance Wire Spaced Tightly for Optimal Heat Uniformity
Contact your local BriskHeat ® representative to have a cloth heating jacket designed for your application.
Material Options Designed for Your Environment including Class 10 Clean rooms
82
