HSTAT

Your Heating Specialist since 1949

XtremeFLEX® HSTAT Silicone Rubber Heating Tapes with Adjustable Thermostat Control
Product Highlights
Built-in adjustable thermostat control
Useful for a wide range of applications
- Process temperature control
- De-icing
- Supplemental heat
Exceptional heater flexibility, durability, and
uniformity
Rapid heat-up and thermal response

HEATING TAPE

Specifications:

• Adjustable thermostat: 50° to 425°F (10° to 218°C)*
• Maximum exposure temperature: 450°F (232°C)
• Moisture and chemical resistant silicone rubber
extruded outer sheath
• Uniform, fiberglass-reinforced serpentine-wound
multi-stranded heating element
• Power density: 6.0 W/in2 (0.009 W/mm2)
• 6-foot (2m) long power cord with

- 120VAC: standard 2-prong NEMA 1-15 plug

- 240VAC: bare wire connection *
• Suitable for electrically conductive surfaces
• Ingress Protection Rating: IP54

Short Video

•
•
•
•

Quickly Heat

Valves
Pipes
Bearings
Pumps

•
•
•
•

Gas tubing
Filter Housings
Actuators
And More!!

Ordering Information:
Width
in (mm)

Length
ft (m)

Total
Watts

Part Number
120VAC

Part Number
240VAC

0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
0.5 (13)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
1.0 (25)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
2.0 (51)
3.0 (76)
3.0 (76)
3.0 (76)
3.0 (76)
3.0 (76)

2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)
2 (0.6)
4 (1.2)
6 (1.8)
8 (2.4)
10 (3.1)

72
144
216
288
360
144
288
432
576
720
288
576
864
1152
1440
432
864
1296
1440
1440/1800

HSTAT051002
HSTAT051004
HSTAT051006
HSTAT051008
HSTAT051010
HSTAT101002
HSTAT101004
HSTAT101006
HSTAT101008
HSTAT101010
HSTAT201002
HSTAT201004
HSTAT201006
HSTAT201008
HSTAT201010
HSTAT301002
HSTAT301004
HSTAT301006
HSTAT301008
HSTAT301010

HSTAT052002*
HSTAT052004*
HSTAT052006*
HSTAT052008*
HSTAT052010*
HSTAT102002*
HSTAT102004*
HSTAT102006*
HSTAT102008*
HSTAT102010*
HSTAT202002
HSTAT202004
HSTAT202006
HSTAT202008
HSTAT202010
HSTAT302002
HSTAT302004
HSTAT302006
HSTAT302008
HSTAT302010

(No plug)

Adhesive Tape

Provides intimate contact with surface to be heated.
Part
Number
PSAT36A
AAT260
AAT2180

Material
Fiberglass
Aluminum
Aluminum

Width
in (mm)
0.5 (13)
2.0 (51)
2.0 (51)

Length
Yards (m)
36 (32.9)
60 (54.8)
60 (54.8)

Temperature
Limit
350°F (176°C)
350°F (176°C)
550°F (288°C)

Celsius Label Option: Add a “-C” at the end of the part number.
Plug not included on 240VAC Models (bare wire leads).
* -C Celsius option has crimped ferrule wire terminated leads.

* If precise temperature control is required for your application, please contact us or your local distributor for application assistance and product solutions.
