TD101

Your Heating Specialist since 1949

TD101 Automatic On/Off Thermostat Control
Product Highlights

TD101X

Ideal thermostat for individual circuits requiring
a weatherproof device
Typical uses:
• Temperature control on heat tracing and
process fluid system applications
• External alarm or an over-temperature limit
switch in conjunction with another control
system

TD101N

Numerous temperature range choices to fit
your application
Mounts directly to heated surface

FM

TD101N series

APPROVED

Class I Division 2
(with conduit fitting)

Specifications:
•
•
•
•
•
•

•

Single pole double throw (SPDT)
Τemperature sensitive bimetal disc
Αverage accuracy of ±15°F (8°C)
Ηermetically sealed black phenolic plastic housing
Rated: 25 Amps, up to 240VAC (CSA)
Maximum exposure temperature -40°F to 221°F
(-40°C to 105°C)
304 Stainless Steel mounting bracket - mounts using
two 0.17” (4.3mm) diameter holes
• Power leads: 4ft (1.2m)
• Ιntegral 3/4” (19mm) NPT male conduit fitting
(TD101X series)

CONTROLLERS

TD101X Suitable for a Class I Division 2
hazardous-area with conduit fitting

TD101X series (with conduit fitting)

Ordering Information:
Part Number

Settings

TD101N

TD101X with
conduit fitting

Volts

Amps

Close °F
(°C)

Open °F
(°C)

TD101N-050

TD101X-050

Up to 277

25

35 (2)

50 (10)

TD101N-060

TD101X-060

Up to 277

25

45 (7)

60 (16)

TD101N-075

TD101X-075

Up to 277

25

60 (16)

75 (24)

TD101N-105

TD101X-105

Up to 277

25

90 (32)

105 (41)

TD101N-200

TD101X-200

Up to 277

25

185 (85)

200 (93)
