TC4X

Your Heating Specialist since 1949

TC4X Digital Temperature Controller in NEMA4X Enclosure
Product Highlights
Simple digital controller suitable for outdoor applications
Temperature control for heat tracing, freeze protection,
and process maintenance applications
Temperature range: -30 to 212ºF (-34 to 100ºC)
A99BB type PTC sensor

Specifications:

CONTROLLERS

• Single-stage, electronic temperature control with a singlepole, double throw (SPDT) output relay
• ΝEMA 4X* watertight, corrosion-resistant enclosure
• 120/240VAC, 60Hz
• 15 amps at 120VAC, 10 amps at 240VAC
• Set-point range is -30 to 212ºF (-34 to 100ºC)
• Displays in ºF or ºC
• Accuracy ±3% of reading
• Wide temperature differential adjustment range: 1 to 30ºF
or ºC
• Adjustable anti-short cycle delay: 0 to 12 minutes in
1-minute increments
• Switch-activated temperature offset function
• Easy-to-read liquid crystal display (LCD) for viewing
temperature and status
• LED indicates the controll er’s output relay On/Off status
• Lockable front panel touchpad
• A99BB type PTC sensor, extendable length, 1/4” (6mm)
sensor diameter
• Remote sensing capability
• Field replaceable sensor
* requires NEMA4X rated fitting for electrical wiring (sold separately)

Ordering Information:
Part Number

Volts

Range

Sensor Lead
Length

TC4X-1

120/240VAC

-30 to 212ºF (-34 to 100ºC)

9” (229mm)

TC4X-2

120/240VAC

-30 to 212ºF (-34 to 100ºC)

78” (1981mm)

Accessories:
Part Number
41276-04

A99BB-200C

Description
1/2” (13mm) diameter watertight conduit fitting suitable
for NEMA 4 and 6 enclosures. Fits cable 0.17” to 0.45” (4 to
11mm) diameter.
A99BB Type PTC replacement sensor. 78” (1981mm) length.
