Choompol Boonmee and Tawa Khampachua
web based application‘ Medical Record’ contextualization. Two software modules have been developed; web page modification module( WebMod # 1) and citizen ID smartcard data retrieving module. WebMod # 1 modifies only the web page which includes input fields of patient’ s personal information by adding java script which retrieves the personal information from the smartcard.
Figure 7: Software architecture of web based software‘ e‐Plan’ contextualization development using client side web page modification technique
Figure 8: Software architecture of web based software‘ Medical Record’ contextualization development using client side web page modification technique and using Thai citizen ID smartcard as external data source
Figure 9 shows the screen layout of web based application‘ Medical Record’ contextualization development using client side web page modification technique. In the web page on left side, there are four text based input fields; ID, name, address and date of birth. The modified page is illustrated on the right side. The button‘ Card’ has been added to the page with corresponding java script. When the citizen ID card is inserted into the smartcard reader and the button is pressed, the personal information is retrieved from the smartcard and is populated in the text fields automatically.
Figure 9: Screen layout of web based software‘ Medical Record’ contextualization development using client side web page modification technique and using Thai citizen ID smartcard as external data source
75
